XTS780 Wireless Control Glass Installation Robot

Basic Info

Model No.: XTS780

Model: XTS780 Glass Installation Robot

Vacuum Pump: CV-35, DC 24V

Max.carrying Capacity: 780kg At Vertical (60% Vacuum Level)

Additional Info

Packaging: Seaworthy packing, wooden box or customized

Productivity: 200sets/month

Brand: Sunshine

Transportation: Ocean,Air,by truck

Place of Origin: Shandong,China

Supply Ability: 200sets/month

Certificate: ISO9001;CE

Port: Qingdao,Shanghai,Guangzhou

Product Description

XTS780 Wireless Control Glass Installation Robot

Main Specifications:

1. Maximum load: 780kg while the second ram back to end, 250kg while the second ram extended

2. Maximum lifting height: 4200mm from ground to the centre of the suction frame

3. Moving: automatically moving, speed control by manual roller sensibly

4. Lifting control: with hydraulic ram, controlled by sensible speed roller

5. extension control: with hydraulic ram, controlled by controlled by sensible speed roller,

    The extension distance about the two arms:

6. tilting control: with hydraulic ram, controlled by sensible speed roller, the maximum tilting

    degree near to 130 degree

7. rotation control: with rotated hydraulic motor, controlled by sensible speed roller, the maximum

     rotation was 180 degree, 90 degree at both sides

8. Side moving: with hydraulic ram, controlled by sensible speed roller, 75mm for both sides,

    totally 150mm

9. side turning: with hydraulic ram, controlled by sensible speed roller, about 25 degree for

    both sides

10. self weight: about 1850kg with counterweight, 1450kg without counterweight

11. Power: DC 24V

12. Driven unit: the front wheels driven with mechanical differential worked as driven unit,

      rear wheels worked for turning

13. Wheels: 450mm*200mm *4 pneumatic wheels in front, dual of 400mm solid wheels

      in rear

14. Driven unit power: DC 24V brush-less motor, 2.2 KW

15. Hydraulic station power: 1.2KW

16. Battery: 12V,210A*2

17. Maximum working period: about 10 Hours continuously

18. Dimensions:3045*850*1700mm

19. Charging power:110-220V

20. Charging time: about 5 hours

21. Vacuum system: Dual pump and dual system with 6 round suction pads, of its dimensions 400mm

Remarks:

Pkg: Seaworthy packing or customized

Terms: FOB/CIF/CFR/EXW

From Qingdao, China To_______,

Delivery Time: During 30 Days After We Receive Your First Payment

Payment: Telex Transfer (T/T), 30% Be Paid After Confirming The Order and

                The rest 70% is effected while delivering the goods



Guarantee & Aftersales service:

1)Guarantee the complete machine for 12 months, except the consumable parts.

2) 24-hours technical support by email or calling.

3) User-friendly English manual for machine using and maintaining.
